Osciloscopio portátil 60MHz 2 canales pantalla
Hantek DSO1062B es un osciloscopio digital portátil de dos canales con el ancho de banda 60 MHz y frecuencia de muestreo 1GSa/s, la particularidad de este osciloscopio es la función de multímetro digital incorporado que permite al usuario medir el voltaje AC/DC, corriente AC/DC, resistencia, capacitancia, testear los diodos y efectuar chequeo de circuitos eléctricos.
Discontinuado
CONSULTE STOCK ANTES DE OFERTAR; SI BIEN LA ROTACIÓN DE ESTE PRODUCTO ES CONTINUA; PUEDE QUE TENGA QUE ESPERAR 15 DÍAS PARA LA ENTREGA.
Osciloscopio digital portátil Hantek DSO1062B siendo bastante compacto y liviano, garantiza exactitud de mediciones y visualización de oscilogramas los, este osciloscopio-multimetro es prefecto para realizar pruebas industriales, mantenimiento de equipos, investigaciones y todo tipo de trabajos, donde se necesita efectuar las pruebas analógicas/digitales y detectar fallas.
Ideal para trabajo de campo. Funciones de osciloscopio y de multimetro (ambos independientes y con formato especifico).
Características:
- Conexión USB.
- Pantalla de 5.7 pulgadas
- Ancho de banda 600MHz+ 6000 cuentas, Multimetro digital de alta precisión
- Frecuencia de muestreo – 1 GSa/s
- Memoria – 1millón puntos.
- frecuencia de barrido 2500 capturas.
- Grabación hasta 1000 oscilogramas.
- 23 tipos de mediciones automáticas.
- Funciones de multímetro de precisión (6000 cuentas):
- Voltaje
- Corriente
- Resistencia
- Capacitancia
- Chequeo de circuitos
- Chequeo de diodos
- Funciones matemáticas: suma, resta, multiplicación, división y FFT.
- Modo X-Y.
- Función de apto/no apto (Pass/Fail).
- Se integra con LabviewVBVC.
- Pantalla LCD a color de 5,6 pulgadas con resolución 640x480.
- Batería de Li recargable (hasta 6 horas de funcionamiento) incorporada.
- Menú cómodo y fácil de usar.
- Sistema multilingüe de ayudas.
- Interface USB Host/Device 2.0 con soporte de dispositivos de almacenamiento USB, opcional RS232/LAN. Fácilmente se maneja desde un PC o de manera remota.
- Compatibilidad con el software: Windows 2000, XP, Vista, Windows 7, Windows 8, Windows 10.
Especificaciones técnicas
| Model | DSO1062B | ||
| Bandwidth | 60MHz | ||
| Channel | 2 | ||
| Real-Sample Rate | 1GSa/s | ||
| Equivalent Sample Rate | 25GSa/s | ||
| Record Length | 1M | ||
| Rish time | ≤5.8ns | ||
| Timebase Accuracy | ±50ppm | ||
| Time Base Range | 4ns/div-40s/div | ||
| Input Impandance | 1MΩ | ||
| VOLTS/DIV Range | 2mV/div～5V/div | ||
| A/D Converter | 8bit | ||
| Position Range | ±50V(5V/div), ±40V(2V/div～500mV/div), ±2V(200mV/div～50mV/div), ±400mV(20mV/div～2mV/div) |
||
| DC Gain Accuracy | ±3% for Normal or Average acquisition mode, 5V/div to 10mV/div; ±4% for Normal or Average acquisition mode, 5mV/div to 2mV/div. |
||
| Bandwidth Limit | 20MHz | ||
| Trigger Types | Edge, Video, Pulse, Slope, Over time, Alternative | ||
| Trigger Source | CH1, CH2 | ||
| Math | +, -, x, ÷, FFT, Invert | ||
| Cursor Measurement | Voltage difference between cursors: △V; Time difference between cursors: △T; Reciprocal of △T in Hertz (1/ΔT); |
||
| Auto Measuerment | Frequency, Period, Mean, Pk-Pk, Cycli RMS, Minimum, Maximum, Rise time, Fall Time, +Pulse Width, -Pulse Width, Delay1-2Rise, Delay1-2Fall, +Duty, -Duty, Vbase, Vtop, Vmid, Vamp, Overshoot, Preshoot, Preiod Mean, Preiod RMS, FOVShoot, RPREShoot, BWIDTH, FRF, FFR, LRR, LRF, LFR, LFF | ||
| DMM Max. Resolution | 6,000 Counts | ||
| Testing Modes | Voltage, Current, Resistance, Capacitance, Diode & Continuity | ||
| Max. Input Voltage | AC: 600V, DC: 800V | ||
| Max. Input Current | AC:10A , DC: 10A | ||
| Max. Input Impandance | 10MΩ | ||
| Display | 5.6"TFT 16K Color Display, 640*480 dots | ||
| Size | 245mm x 163mm x 52mm | ||
| Weight | 1.3KG(Without Package) | ||
| Standard Probe | PP80x2 | ||
La compra incluye
- Osciloscopio Hantek DSO1062B (1 ud.)
- Sondas para multímetro (2 uds.)
- Sondas para osciloscopio (2 uds.)
- Cable USB (1 ud.)
- Maletín (1 ud.)
- Fuente alimentación 12V (1 ud.)
- Manual de usuario (1 ud.)
